Arcam A39 integrated amplifier

Arcam A39 integrated amplifier

A one careful owner example of the Arcam A39 integrated amplifier. Condition is excellent, full working order. It comes with the manual, handset and mains lead and original box, although we will have to fabricate some internal packing.

£650 + £15 carriage

held for customer



The Arcam A39 incorporates 40 years worth of design knowledge to give you an amplifier that is setting new standards providing class-leading sound for perfect musical reproduction.Incorporating a class G amplifier, with a toroidal based power supply, acoustically damped chassis, paralleled transistor output stages and exceptionally low levels of distortion and noise the A39 is capable of reproducing music with all its original authority and detail. The A39 has been designed to leapfrog the competition with a massive 120 watts per channel into 8 ohms and 240 into 4 ohms.

It delivers 20 watts in pure class A mode while allowing for huge extra power reserves from our latest generation class G topology that is both clever and efficient. During normal operation, distortion is measured in less than one part per million so that this massive power is delivered with total control and finesse.

We are an authorised Arcam dealership.



Features:

  • Integrated stereo amplifier with twin speaker outs
  • 120W Class G amplification, 20W in class A
  • On board PSU for rSeries products
  • CR902 system remote control
  • Phono input configurable for line/MM
  • Large ergonomically designed aluminium knob
  • Low power 0.5W standby

Specifications:

  • Continuous power output (20Hz—20kHz at 0.5% THD), per channel
  • Both channels, 8O, 20Hz—20kHz: 120W
  • Single channel, 4O, at 1kHz: 240W
  • Harmonic distortion, 80% power, 😯 at 1kHz: 0.001%

Inputs

  • Phono (MM) cartridge:
  • Input sensitivity at 1kHz: 5mV
  • Input impedance: 47kO + 270pF
  • Frequency response (ref. RIAA curve): 20Hz—20kHz ± 1dB
  • Signal/Noise ratio (Awtd) 50W, ref. 5mV input: 80dB
  • Overload margin, ref. 5mV at 1kHz: 20dB

Preamplifier output

  • Nominal output level: 900mV
  • Output impedance: 240O

Inputs:

  • Nominal sensitivity: 1V
  • Input impedance: 10kO
  • Maximum input: 4.6V
  • Frequency response: 20Hz—20kHz ± 0.2dB
  • Signal/noise ratio (Awtd) 50W, ref. 1V input: 105dB

Headphone output

  • Maximum output level into 600O: 4V
  • Output impedance: 1O
  • Load range: 16O—2kO

Accessory power output

  • 2.1mm DC connector: 6V, 1A

General

  • Mains voltage: 110–120V~ or 220–240V~
  • Power consumption (maximum): 1kW
  • Dimensions W x D x H (including feet): 433 x 425 x 100mm
  • Weight (net): 11.5kg
  • Weight (packed): 13.2kg

Supplied accessories

  • Mains lead
  • CR902 remote control
  • 2 x AAA batteries
  • Accessory power cable

‘it sounds very powerful and gutsy, yet has a natural musical zeal that grips the listener and doesn’t let go’Hi-Fi Choice Awards – 5 Star
